Harris 3200710 Hp Single-Stage Pressure Regulator – Model 8700Ss-1500-680 1

Harris 3200710 Hp Single-Stage Pressure Regulator – Model 8700Ss-1500-680

Original price was: $1,308.33.Current price is: $92.73.

In stock

Quantity
SKU: 3200710 Category: Brand:

Description

Harris HP Single Stage Pressure Regulator Model 8700SS-1500-680 – 3200710

Model HP8700SS is a Single Stage Stainless Steel Regulator that is designed to operate on Two Stage Ultra high-pressure Cylinders up to 7500 psig. The Model HP8700SS is suitable for high pressure testing charging accumulators and pressurizing struts for hydraulic systems and aircraft/heavy equipment.. This model features a Stainless Steel body, fittings and gauges (psi/bar) and chrome-plated brass bonnet, ergonomic plastic knob for improved grip and ease of adjustment of the delivery pressure, and one-piece encapsulated seat that is design with internal filter and CTFE (Kel F™) seat. It has a 1/4″” NPT outlet with Stainless Steel 1/4″” tube fitting.

Features

  • Operates on high pressure Cylinders up to 7500 psig
  • Stainless Steel body and fittings and chrome-plated brass bonnet for longer service life
  • Ergonomic ABS plastic knob for improved grip and precise adjustment
  • 2.5″” Stainless Steel dual scale easy-to-read gauges (psi/bar)
  • One-piece encapsulated seat design with 10 micron sintered internal filter to protect the PCTFE (Kel-F™) seat from particulate contamination
  • Urethane diaphragm for greater flexibility
  • 1/4″” NPT outlet with Stainless Steel 1/4″” tube fitting
  • Suitable for high pressure testing, charging accumulators and pressurizing aircraft struts
  • Conforms to CGA E-4 standard for gas pressure Regulators

A table titled Materials for the Harris 8700SS-3000-000 - 3200701 HP Single Stage Pressure Regulator lists components like Body, Bonnet, Diaphragm, Nozzle, Seat, Filter, Adjusting Knob, and Outlet with materials such as stainless steel and brass.

A table titled Harris 8700SS-3000-000 - 3200701 HP Single Stage Pressure Regulator Ordering Information lists part numbers, model numbers, gas types, max inlet and delivery pressures, and gauge ranges for this stainless steel single stage regulator.

A comparison chart displays specs and dimensions for the Harris 8700SS-3000-000 - 3200701 HP Single Stage Pressure Regulator, covering weights, pressure rise, Cv values, and technical diagrams for both non-venting and self-venting models.
