Harris 3500-200-580 High-Pressure Single Stage Argon/Helium/Nitrogen Regulator – 3003511
Model 3500 high-pressure, high-flow Argon/Helium/Nitrogen Regulator is specifically designed to provide high gas flows from Cylinders and to supply manifold gas systems. It is also ideal for special high-flow Cylinder applications such as heavy cutting and heating. It has dual port outlets and a neoprene diaphragm. Includes a 3/8 in. NPT auxiliary port.
Features
- Operates on high pressure Cylinders up to 3000 PSIG
- Ideal for special high flow Cylinder applications
- Easy-to-operate brass T-screw bar adjusting handle
- Brass body and bonnet for longer service life
- Large 2.75 in. neoprene diaphragm for improved pressure control
- 2.5 in. Brass dual scale easy-to-read gauges
- One-piece encapsulated seat design with internal filter to protect the CTFE Kel-F seat from particulate contamination
- Equipped with a tamper-proof, self-reseating, internal high pressure safety relief valve
- This model has dual outlet ports
- Features 3/8 in. NPT outlet connection auxiliary port
Specifications
Equipment
| Adjusting Screw | Brass T-screw bar |
| Body | Brass |
| Bonnet | Brass |
| Capacity | High pressure High flow |
| Certification | CGA E-4 |
| Cv | 0.4 |
| Delivery Pressure Gauge (PSIG) | 400 |
| Delivery Pressure Range (PSIG) | 0 – 200 |
| Diaphragm | Neoprene |
| Equipped With | Dual port outlets 3/8 in. NPT auxiliary port |
| Gas / Gas Service | Argon Helium Nitrogen |
| Gauges | 2.5 in. Brass dual scale |
| Inlet Connection | CGA 580 |
| Maximum Inlet Pressure (PSIG) | 3000 |
| Outlet Connection | 5/8 in. – 18 RH |
| Pressure Regulation PSIG/100 PSIG | 0.9 |
| Recommended Items/Accessories | Plug – Model 967 1/4 in. NPT – PN 9000306 Plug – Model 967 3/8 in. NPT Hex Socket – PN 9000373 |
| Seat | PCTFE (Kel-F™) |
| Supply Pressure Gauge (PSIG) | 4000 |
Warranty
| Warranty | 1 Year |
